Jenny G9HGA-17P 9HP 17GAL Compressor

Standard Features

• Heavy-duty single stage cast iron compressor pump Made in Somerset, PA USA
• Splash lubricated
• Belt driven with a large flywheel for extra cooling and easier start-up
• Each unit is filled with Jenny Ultimate Blue Compressor Pump Oil
• Directional air shroud for reduced pump temperatures
• Totally enclosed heavy-duty belt guard
• 8 & 15 gallon tanks are low profile, powder coated twin tank receivers
• 17 and 30 gallon tanks are powder coated and ASME certified
• Oil sight glass
• Convenient lifting handles
• Anti-vibration feet
• Pneumatic tire(s)
• Protectively mounted fittings
• Manual tank drain(s)
• Large canister intake filter with replaceable filter elements
• Special unloading valves to assist in motor starting
• Stainless steel braided discharge hose
• Tank gauge
• Regulator and outlet pressure gauge
• Pressure relief safety valve
• Designed, tested and proven to meet the demands of the construction and rental industry

Electric Motor

• Constant run control set at 105-125 PSI
• High quality pilot valve
• Industrial/Commercial grade UL Listed electric motor
• Thermal overload motor protection
• 6 ft power cord

Options

• Start-Stop control n Dual control
• Dual voltage switch n On-Off switch
• Two wheel option (8 & 15 gallon models)
• Discharge Unloader n Air line filter n Lubricator
• Other pressures available upon request
